TESLA MODEL Y (2020+) SERVICE WORKSHOP MANUAL IN PDF FORMAT (~10000 pages). THIS HIGH RESOLUTION DIGITISED MANUAL IS AVAILABLE BOTH AS DOWNLOADABLE LINK AND PEN DRIVE SHIPPED.
THE MANUAL CAME OUT FOR A VERY RESTRICTED AUDIENCE AND HERE IS YOUR CHANCE TO BE PART OF IT.
TESLA WORKSHOP MANUAL IS TYPICALLY FOR EDUCATIONAL INSTITUTIONS, AMATEURS OF REVERSE ENGINEERING OR SIMPLY FOR SOMEONE CURIOUS TO KNOW IN DETAILS HOW A TESLA WAS ENGINEERED.
POWERTRAIN
Powertrain
Electric motor: Permanent magnet synchronous reluctance motor
Battery 67.6–81 kWh lithium-ion
Electric range:
244 mi (393 km) (SR RWD)
279 mi (449 km) (AWD)
303 mi (488 km) (Performance)
326 mi (525 km) (LR AWD)
Plug-in charging11 kW onboard charger at 48 A AC
250 kW DC
