AGCO ST35, ST40 Tractor Service Manual Workshop Guide

AGCO ST35, ST40 Tractor Service Manual (effective "L" S/N) : 320 Pages AGCO ST35, ST40 Tractor  Service Manual (Prior "L" S/N) : 341 Pages Hydro Version : 308 Pages Engine Manual: 124 Pages Manual for: AGCO Tractor Format: PDF Book Number: 79023088 & 79021618 & 79019398 English Description AGCO ST35, ST40 Compact Tractor Manual Manual for: AGCO Tractor Format: PDF Book Number: 79023088 & 79021618 & 79019398 English AGCO ST35, ST40 Tractor Service Manual (effective "L" S/N) : 320 Pages AGCO ST35, ST40 Tractor  Service Manual (Prior "L" S/N) : 341 Pages Hydro Version : 308 Pages Engine Manual: 124 Pages Manual TABLE OF CONTENTS INTRODUCTION …………………………………………………………………… 01 SHEET METAL ……………………………………………………………………… 01A MAJOR COMPONENTS …………………………………………………………. 01 B ENGINE …………………………………………………………………………………02A COOLING SYSTEM AND AIR CLEANER …………………………………..03A CLUTCH ……………………………………………………………………………….. 04A TRANSMISSION …………………………………………………………………….05A POWER SHUTTLE ………………………………………………………………… 05B HYDROSTAT ………………………………………………………………………… 05C FRONT AXLE (2 WD) ……………………………………………………………. 06A FRONT AXLE (4WD) ………………………………………………………………06B REAR AXLE AND BRAKES ……………………………………………………. 07A POWER ASSIST STEERING ……………………………………………………08A HYDRAULIC SYSTEM ……………………………………………………………09A ELECTRICAL SYSTEM …………………………………………………………. 10A ST35, ST40 Manual Extract – FORWARD/REVERSE SHIFT Removal and Installation FIG. 5A-76: Linkage is shown. 1. Shift Fork 2. Shift Rail 3. Fork 4. Lever 5. Cable Assembly 6. Shift Cover 7. Oil Seal 8. Arm 9. Gasket Disassembly · Split Tractor between front transmission and engine. · Remove bolts holding shift housing and remove housing. · Remove wires holding shift rail retaining bolts and remove rail with fork. · When removing shift rails be careful that detent balls do not fly out and become lost. Reassembly · Reverse procedures to install shift linkage with the following additional information. · Lubricate grooves in shift rails
