Ammann ARX 26-2, ARX 26-2C Tandem Roller Workshop Repair Manual Workshop Guide

Manual Included: Workshop Repair Manual: 344 Pages Operation Manual: 158 Pages Spare Parts Catalog: 196 Pages Kubota D1803 Engine Operation and Spare Parts Manual are also included. Specifications: Brand: Ammann Model: ARX 26-2, ARX 26-2C Type: Tandem Roller Manuals: Workshop, Repair, Operation and Parts Manual Language: English Format: PDF Description Table of Content – Ammann ARX 26-2, ARX 26-2C Tandem Roller Repair Manual 1 INTRODUCTION 2 SAFETY MEASURES AND INSTRUCTIONS 3 SPECIFICATION MANUAL 4 SPECIFICATION OF OPERATING FLUIDS 5 FRAME 6 CAB AND PLATFORM 7 FRONT DRUM 8 REAR DRUM 9 FRONT AXLE (NOT PART OF MACHINE EQUIPMENT) 10 REAR AXLE 11 TRAVEL 12 VIBRATION 13 STEERING 14 COOLING 15 ENGINE 16 OPTIONAL EQUIPMENT 17 GENERAL PROCEDURES 18 TROUBLESHOOTING 19 ANNEXES About this workshop manual This workshop manual is intended for service technicians in the field and a workshop who are authorized by the user to perform servicing and maintenance. The purpose of this workshop manual is to provide instructions for optimal use and safe operation of the roller, while ensuring the following processes: Maintenance Repairs This manual applies to the following models: ARX 26-2, ARX 26-2C Because the roller can be fitted with various optional equipment, some illustrations or descriptions in this manual may differ from those of your particular machine. Repairs on this machine must only be performed by qualified, professionally trained, and experienced personnel, or by service staff from our authorized dealerships. Always consult this workshop manual before commencing any repair work. Individual chapters include special instructions and guidelines for disassembly and assembly tasks.
