Case 1150M Crawler Dozer Service Manual Workshop Guide

Manual Included: • Service Manual: Stage 3B- 2136 Pages & 2202 Pages, Tier 2 – 1778 Pages & 1848 Pages, Tier 4B (final) – 2082 Pages and Tier 4A (interim) – 2282 Pages Specifications: • Brand: New Holland • Model: 1150M Stage IIIB • Type: Crawler Dozer • Manuals: Service Manual • Publication Numbers: 48080034 • Language: English • Format: PDF Description Table of Content ( Service Manual) Contents Introduction Maintenance Engine Power Coupling Hydrostatic Drive Brakes and Controls Hydraulic Systems Hitches, drawbars and implement couplings Tracks and Track Suspension Cab Climate Control Electrical System Lubrication System Dozer Blade and arm Tools Platform, cab, bodywork and decals Specials Tool Index Electrical Schematics Hydraulics Schematics Manual Extract: Cab air filters – Remove 1. Park the machine on a firm level surface. 2. Lower the blade and ripper tool (if so equipped). 3. Engage the park brake and turn the ignition key to the OFF position. 4. Locate the battery master disconnect switch behind the panel on the left side of the cab. 5. Switch the master battery disconnect switch to the OFF position. NOTE: Wait 90 seconds after engine shutdown before turning off the master battery disconnect. After engine shut down, the Selective Catalytic Reduction (SCR) system does a purge cycle and the supply module continues to run 6. Locate the cab air filter element behind the operator's compartment. 7. Access the cab air filter element using the steps located on the ripper, the draw bar or the hitch and the grab handles located at the rear of the machine. NOTE: Machine configurations and step locations may differ. 8. Remove the screws from the cab air filter element outer cover. 9. Remove the cab air filter element outer cover. 10. Remove the screws from the cab air filter element inner cover. 11. Remove the cab air filter element inner cover. 12. Remove the cab air filter element. 13. Remove any additional debris from inside the cab air filter element housing.
