Case 1221F Wheel Loader Service Manual Workshop Guide

Manual Included: Service Manual: 682 pages Specifications: Brand: New Holland Model: Case 1221F Type: Wheel Loader Manuals: Service Manual Publication Numbers: 47544213 (August 2013) Language: English Format: PDF Description Table of Contents Foreword Contents General Engine Power Train System Brake and Fan System Steering System Work Equipment Electrical System Electrical Schematics Manual Extract: POWER TRAIN COMPONENT OVERVIEW The power train consists of the following components: -Transmission -Front, center, rear and upper drive shafts -Front and rear axles Engine power is transmitted to the transmission through the torque converter. The transmission is a hydraulically engaged four speed forward, three speed reverse countershaft type power shift transmission. A caliper-disc type parking brake is located on the front axle. The transmission outputs through universal joints to three drive shaft assemblies. The front drive shaft is a telescoping shaft which drives the front axle. The front axle is mounted directly to the loader frame. The front axle is equipped with hydraulic lock differential. The rear axle is mounted on an oscillating pivot. The rear axle is equipped with conventional differential. The power transmitted to front axle and rear axle is reduced by the pinion gear and ring gear of differential. It then passes from the differential to the sun gear shaft (axle shaft) of final drive. The power of the sun gear is reduced by a planetary mechanism and is transmitted through the planetary hub to the wheel. Identify the Tier Level of your Equipment (Read our Article on Tier Level )
