Case 1850K Crawler Dozer Service Manual Workshop Guide

Manual Included: • Service Manual: 465 pages Specifications: • Brand: New Holland • Model: 1850K • Type: Dozer • Manuals: Service Manual • Publication Numbers: 87388581A • Language: English • Format: PDF Description Table of Contents Generalities Engine Transmission Final Drives Brakes and Steering Undercarriage Dozer Equipment Hydraulic System Electrical System Air Conditioning Unit Manual Extract: HIGH PRESSURE PIPES, CONNECTIONS, HOSES AND PIPES This section provides correct recommendations and procedures to be followed during the disassembly of pipes and relevant connections. – Keep all internal and external threads clean. – Remove the plugs just before connecting the pipes and plug at once all open connections. – Do not use or reuse semi flanges out of shape more than 0.6 mm in the Centre (see figure). – Make sure that the seats of O-Rings are undamaged. – Lubricate all O-Rings. – Make sure that O-Rings are in place in the relevant seat. – Tighten regularly so as to avoid distortions or damages to O-Rings. – Install pipes and support bands letting the latter slightly loosen (tighten the band only after tightening the connections).
