Manual Included:
•
Service Manual:
606 pages
Specifications:
•
Brand:
Case
•
Model:
325
•
Type:
Articulated Truck
•
Manuals:
Service Manual
•
Publication Numbers:
9-35401
•
Language:
English
•
Format:
PDF
Description
Table of Contents
Content
Maintenance
General Instructions
Engine
Transmission
Front Axle
Rear Axle
Brakes System
Hydraulic System
Steering
Wheels
Electrical System
Cab and Chassis
Manual Extract: Input Shaft
1. Heat the gear to about 120 °C (248 °F) and assemble until contact is obtained.
2. Install the gear with the snap ring.
3. Install the snap ring into the recess of the turbine shaft.
4. Install the turbine shaft until the snap ring snaps into the recess of the input shaft.
