Case 350, 400, 450, 600 Steiger Tractor Service Manual Workshop Guide

Manual Included: • Service Manual: 4883 pages Specifications: • Brand: Case • Model: 350, 400, 450, 600 Steiger • Type: Tractor • Manuals: Service Manual • Publication Number: 47488212 (Feb 2013) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Transmission Front Axle System Rear Axle System Power Take Off (PTO) Brakes and Controls Hydraulic Systems Hitches, drawbars and implement couplings Frames and ballasting Steering Wheels Tracks and Suspension Cab Climate Control Electrical System Platform, cab, bodywork and decals Special Tool Index Manual Extract: Receiver/Dryer – Static description The receiver/drier orientation is critical. Make sure the outlet flange is within 5 ° of true level (the decal should face up). The receiver/drier must be installed with the inlet connected to the hose from the condenser and the outlet connected to the hose going to the thermal expansion valve. The receiver/drier is normally the last item replaced when servicing the system, just before the system is evacuated. This prevents saturating the drier with moisture. When servicing the receiver/drier, use the two hand, two wrench method to prevent damage to the tubes and fittings when you loosen or tighten the tube connections. Always install new O-rings when the receiver/drier is connected to the system. Lubricate the O-rings with clean mineral oil prior to installation.
