Case 570N EP Wheel Loader Service Manual Workshop Guide

Manual Included: • Service Manual: 1928 pages Specifications: • Brand: Case • Model: 570N EP • Type: Loader • Manuals: Service Manual • Publication Numbers: 47821917 (April 2015) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Transmission Front Axle Rear Axle Power Take Off (PTO) Hydraulic System Hydraulic System Wheels Cab climate control Electrical System Front Loader and Bucket Platform, Cab, Bodywork and Decals Electrical Schematic Hydraulic Schematic Manual Extract: Transmission drive and driven shafts – Disassemble Primary shaft 1. Put the primary shaft on the bench so that the end with the bearing attached is up. Remove the snap ring. 2. Install a bearing separator under the gear as shown. DO NOT install the bearing separator between the gear and the bearing. Install an acceptable puller on the bearing separator. Use a shaft protector between the puller and the end of the primary shaft. Use moly disulfide grease to lubricate the shaft protector and the end of the puller. Pull the bearing from the primary shaft. 3. Remove the bearing. 4. Remove the thrust washer. 5. Install a bearing separator under the lip of the bearing race as shown. Install an acceptable puller on the bearing separator. Use a shaft protector between the puller and the end of the primary shaft. Use moly disulfide grease to lubricate the shaft protector and the end of the puller. Pull the bearing race from the primary shaft.
