Case 570T Backhoe Loader Service Manual Workshop Guide

Manual Included: Service Manual: 1243 pages Specifications: Brand: New Holland Model: Case 570T Type: Backhoe Loader Manuals: Service Manual Publication Numbers: 47576089 (June 2014) Language: English Format: PDF Description Table of Contents Content Introduction Engine Four Wheel Drive System Front Axle Rear Axle Hydrostatic Drive Brakes and Controls Hydraulic System Frames and Ballasting Steering Wheels Cab Climate control Electrical System Front Loader and Bucket Booms, dipper and buckets Platform, Cab, Bodywork and Decals Special Tool Index Manual Extract: Front axle – Troubleshooting Problem Possible Cause Correction Steering is difficult; vehicle goes straight while it's turning Incorrect installation/defective axle Correct installation or repair or replace the differential in case it does not survive any one of the test phases Overloading/incorrect weight distribution Remove excessive weight and redistribute load, following instructions related to the vehicle Different rotation radius of the tires If one tire has a smaller radius, it will cause partial wheel slipping when force is applied. The other tire with bigger radius will have to support all the work. Replace the tire or adjust pressure to have same radius on both tire Broken half shaft It is not advisable to operate the vehicle with a broken half shaft. It is acceptable to move the vehicle (engine "Off" unloaded) a few meters away only Incorrect use of the product See the vehicle producer's instructions once again
