Case 580N, 580SN WT, 580SN, 590SN Backhoe Loader Service Manual Workshop Guide

Manual Included: Service Manual: 2945 Pages & 3602 Pages Specifications: Brand: New Holland Model: Case 580N, 580SN WT, 580SN and 590SN Type: Backhoe Loader Manuals: Service Manual Publication Numbers: 47830958 (August 2015) and 47860801 (August 2015) Language: English Format: PDF Description Table of Contents Content Introduction Engine Four Wheel Drive System Front Axle Rear Axle Hydrostatic Drive Brakes and Controls Hydraulic System Frames and Ballasting Steering Wheels Cab Climate control Electrical System Front Loader and Bucket Booms, dippers and buckets Platform, Cab, Bodywork and Decals Special Tool Index Manual Extract: Hydraulic contamination All hydraulic systems operate with some contamination. The design of the components in this hydraulic system permits efficient operation with a small amount of contamination. An increase in this amount of contamination can cause problems in the hydraulic system. The following list includes some of these problems: • Cylinder rod seals that leak • Control valve spools that do not return to neutral • Movement of control valve spools is difficult • Hydraulic oil that becomes too hot • Pump gears, housing, and other parts that wear rapidly • Relief valves or check valves held open by dirt • Quick failure of components that have been repaired • Slow cycle times are slow. The machine does not have enough power. If your machine has any of these problems, check the hydraulic oil for contamination Identify the Tier Level of your Equipment (Read our Article on Tier Level )
