Case 580T, 580ST, 590ST, 690ST Backhoe Loader Service Manual Workshop Guide

Manual Included: • Service Manual: 2021 Pages & 3131 Pages Specifications: • Brand: Case • Model: 580T, 580ST, 590ST, 690ST • Type: Loader • Manuals: Service Manual • Publication Numbers: 48090752 (Feb 2017) & 47847146 (June 2013) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Power Coupling Front Axle Rear Axle Hydraulic System Brakes and Controls Hydraulic System Frames and Ballasting Steering Wheels Cab climate control Electrical System Front Loader and Bucket Boomers, dippers and buckets Platform, Cab, Bodywork and Decals Special Tool Index Electrical Schematics Hydraulic Schematics Manual Extract: Front axle – Install Prior operation: Front axle – Remove (25.400) 1. Raise the axle into alignment with the machine. 2. Install a spacer (5) between the front of the axle and the frame. 3. Start the pivot pin (4) into the frame, spacer(s) (5) and axle. 4. Drive the pivot pin (4) into the rear pivot of the axle but not through the rear pivot. 5. Install the washer (2) between the rear of the axle and the frame. NOTE: Remove or install washer(s) (2) as required between the axle and the frame to remove any and play. 6. Drive the pivot pin (4) through the rear pivot and the frame. 7. Install the bolt and snap rings. 8. Connect the lubrication hose (1) to the fitting. 9. Loosen and remove the plugs from the hoses and the caps from the fittings for the steering cylinder. 10. Connect the hoses to the steering cylinder. 11. Install the wheels and wheel bolts. do not use an impact wrench to tighten the wheel bolts. Refer to Front wheels – Install (44.511). 12. Remove the stands and lower the wheels to the floor. 13. Lubricate the pivot pin (4) for the axle. 14. Check and adjust the toe-in according to Four-Wheel Drive (4WD) axle – Drawing – Front axle-four wheel drive- measuring toe-in (25.100).
