Case 586H, 588H Forklift Service Manual Workshop Guide

Manual Included: • Service Manual: 1405 pages & 1604 pages Specifications: • Brand: Case • Model: 586H, 588H • Type: Forklift • Manuals: Service Manual • Publication Numbers: 47421773 (Aug 2012) & 47821916 (April 2015) • Language: English • Format: PDF Description Table of Contents Introduction Engine Transmission Front Axle Rear Axle Brakes and Controls Hydraulic Systems Frames and ballasting Steering Wheels Electrical System Telescopic single arm Platform, cab, bodywork and decals Special Tool Index Electrical Schematic Hydraulic Schematic Manual Extract: Differential – Inspect 1. Clean all parts in cleaning solvent. 2. Inspect the bearing cup and the rollers in the bearings for flat areas, pitting, scoring, and other damage. Also check the inner race for damage. If any of these defects are found, a new bearing and bearing cup must be installed. 3. Inspect the teeth on the pinion gear and ring gear for pitting, scoring, and broken teeth. The ring gear and pinion gear must be replaced as a set. 4. Inspect the side gears, the pinion shaft, and the teeth of the pinion gears for pitting, scoring, and other damage. Also inspect the thrust surfaces and the bore of each pinion gear. Check the splines in the side gears for wear. Use new parts as required. 5. Inspect the thrust washers for pitting, scoring, and other damage. Use new parts as required.
