Case 721E Wheel Loader Service Manual Workshop Guide

Manual Included: • Service Manual: 1849 pages, 933 pages and 816 pages Specifications: • Brand: Case • Model: 721E • Type: Loader • Manuals: Service Manual • Publication Numbers: 71114022 (Feb 2016), 84243980 (Dec 2009) and 87551874 • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Transmission Front Axle Rear Axle Hydraulic System Brakes and Controls Hydraulic System Steering Wheels Cab climate control Electrical System Front Loader and Bucket Platform, Cab, Bodywork and Decals Special Tool Index Manual Extract: Brake pump – Remove with fan pump Prior operation: Ladder – Remove (90.118), Cab suspension – Remove (90.150) NOTE: Hydraulic pump suction hose removed for picture clarity. 1. Drain the hydraulic tank. 2. Remove the hydraulic pump suction hose (not shown). 3. Remove the brake pump-to-brake valve hose (1). 4. Remove the valve tube (2). 5. Attach lifting equipment to the brake pump/fan pump assembly. Remove the fan pump mounting bolts (1). Remove brake pump/fan pump assembly.
