Case 721F Wheel Loader Service Manual Workshop Guide

Manual Included: • Service Manual: 2331 pages & 1020 pages Specifications: • Brand: Case • Model: 721F • Type: Loader • Manuals: Service Manual • Publication Numbers: 47881872 (June 2015) & 84488413 (April 2011) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Transmission Four Wheel Drive System Front Axle Rear Axle Hydraulic System Frames and ballasting Steering Wheels Cab climate control Electrical System Front Loader and Bucket Platform, Cab, Bodywork and Decals Special Tool Index Manual Extract: Brake pump – Remove with fan pump 1. Remove and discard the bolts and straps that fasten the engine drive shaft to the transmission. NOTICE: the bolts and straps that fasten the engine drive shaft to the transmission must be replaced when removed. 2. Loosen and remove the six bolts that fasten the engine drive shaft to the engine. NOTE: the bolts that fasten the engine drive shaft to the engine must be replaced when removed. 3. Remove the engine drive shaft from the machine.
