Case 821E Wheel Loader Service Manual Workshop Guide

Manual Included: • Service Manual: 1849 pages & 855 pages Specifications: • Brand: Case • Model: 821E • Type: Loader • Manuals: Service Manual • Publication Numbers: 71114025 (Feb 2016) & 84299244 (Dec 2009) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Transmission Front Axle Rear Axle Brakes and Controls Hydraulic System Steering Wheels Cab climate control Electrical System Front Loader and Bucket Special Tool Index Manual Extract: STEERING PRIORITY VALVE REMOVAL 1. Park loader on level ground and lower bucket to ground. Put transmission in NEUTRAL, apply parking brake, and shut down engine, 2. Put master disconnect switch in OFF position. 3. Remove all dirt and grease from steering priority valve (7) and adjacent area. See illustration on page 11. 4. Remove hydraulic reservoir fill cap. 5. Connect a vacuum pump to hydraulic reservoir. 6. Start vacuum pump. 7. Tag and disconnect all hoses connected to the steering priority valve (7). 8. Loosen and remove eight bolts (4) and four spit flanges (3). 9. Remove the high pressure pump discharge tube (5), discard O-rings (6). 10. Support the steering priority valve (7), remove mounting bolts (8). 11. Remove steering priority valve (7).
