Case 821F, 921F Wheel Loader Service Manual Workshop Guide

Manual Included: Service Manual: 2304 pages Specifications: Brand: New Holland Model: Case 821F and 921F Type: Wheel Loader Manuals: Service Manual Publication Numbers: 47673352 (March 2014) Language: English Format: PDF Description Table of Contents Content Introduction Engine Four Wheel Drive System Front Axle Rear Axle Hydrostatic Drive Brakes and Controls Hydraulic System Frames and Ballasting Steering Cab Climate control Electrical System Front Loader and Bucket Platform, Cab, Bodywork and Decals Special Tool Index Manual Extract: Cab climate control – Air conditioning Air Louvers 1. Make sure louvers and recirculation vents are fully open for most efficient air conditioning operation. Defrost louvers must be closed. 2. Check blower; blower must be running. Air Conditioning NOTICE: Use caution when feeling hoses. Hoses become very hot. Check temperature by slowly reaching for hose and touching briefly several times with finger tips, increasing the duration with each touch. 1. Feel the air conditioning hoses. The high pressure hoses (small line) must be warmer than the low pressure hose (large line). 2. If no temperature difference, the system is low on refrigerant, or compressor is not working correctly. Duct Temperature 1. Put a thermometer in the air duct behind the seat and run the compressor for five minutes to make temperature stable. 2. Duct temperature must be below 25 °C (77 °F) if the system is operating at maximum efficiency. 3. If temperature is above 25 °C (77 °F), system is low on refrigerant, there is a restriction in the system, compressor is not working correctly, or air ducts are not sealed correctly." NOTE: Ambient temperature must be 27 – 43 °C (81 109 °F). Identify the Tier Level of your Equipment (Read our Article on Tier Level )
