Case 821G, 921G Wheel Loader Service Manual Workshop Guide

Manual Included: • Service Manual: 2943 pages, 2935 pages and 2203 pages (Tier 2) Specifications: • Brand: Case • Model: 821G, 921G • Type: Loader • Manuals: Service Manual • Publication Numbers: 51428267 (Dec 2017), 51428216 (Nov 2017) & 48083741 (Jul 2018) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Transmission Front Axle Rear Axle Hydraulic System Brakes and Controls Hydraulic System Steering Wheels Cab climate control Electrical System Front Loader and Bucket Platform, Cab, Bodywork and Decals Special Tool Index Manual Extract: Loader arm and bucket control system – Remove – Electro-Hydraulic (EH) lift sensor 1. Park the machine on a level surface and lower the bucket to the floor. Stop the engine and apply the parking brake. 2. With the engine stopped, move the joystick or control lever(s) to release any pressure in the hydraulic circuit. 3. Locate the Electro-Hydraulic (EH) lift sensor assembly on the right-hand of the front frame. Disconnect the electrical connector X-BOA (arrow) from the Electro-Hydraulic (EH) lift sensor (1). 4. Loosen and remove the three bolts (5), washers (4) and spacers (3) that fix the EH lift sensor assembly (1) to the front frame. 5. Remove the hexagon socket screw (2) from the arm fork of the EH lift sensor assembly (1). Remove the EH lift sensor assembly (1) from the machine.
