Case 836C, 836C AWD, 856C, 856C AWD Grader Service Manual Workshop Guide

Manual Included: • Service Manual: 1273 Pages and 2049 Pages Specifications: • Brand: Case • Model: 836C, 836C AWD, 856C, 856C AWD • Type: Grader • Manuals: Service Manual • Publication Numbers: 47829048B (June 2016) & 47829048 (Jan 2015) • Language: English • Format: PDF Description Table of Contents Contents Introduction Engine Transmission Front Axle System Rear Axle System Hydrostatic Drive Brakes and Controls Hydraulic Systems Frames and Ballasting Steering Wheels Cab Climate Control Electrical System Dozer blade and arm Platform, Cab, Bodywork and Decals Specials Tool Index Manual Extract: Loader bucket control cylinder – Disassemble 1. Open the hood (1). 2. Drain the engine coolant. 3. Locate the DEF/ADBLUE® Heater Control valve up to Supply Module on the right–hand side of the engine. 4. Disconnect the machine wiring harness (2) from the DEF/ADBLUE® heater control valve. Using a small flat blade screw driver, pull up on the fitting retaining clip and disconnect the coolant inlet (3) /outlet (5) and by-pass (4) lines from the heater control valve (1) 5. Remove the hexagonal bolts (6) securing heater control valve to the mounting support bracket and remove the heater control valve (1) from machine.
