Case CX15B, CX18B Series 2 Mini Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 879 pages Specifications: • Brand: New Holland • Model: CX15B, CX18B Series 2 • Type: Mini Excavator • Manuals: Service Manual • Publication Numbers: 84533370B (May 2014) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Electrical System Booms, dippers and buckets Dozer Blade and Arm Platform, cab, bodywork and decals Manual Extract: Cylinder head – Assemble Installation of cylinder head gasket NOTE: Do not use liquid gasket. 1. Make sure that there is no dirt or dents on the top surfaces of the cylinder block and pistons. 2. Screw in two guide bolts  in the bolt holes of the block. 3. Place the new cylinder head gasket on the cylinder block using the guide bolts as a guide. NOTE: The model name is stamped on the front top face of the gasket so that it is not confused with one for other model. Installation of cylinder head assembly Install the cylinder head by means of the guide screws
