Case CX210C Crawler Excavator Service Manual Workshop Guide

Manual Included: Service Manual: 2638 Pages & 3022 Pages Specifications: Brand: New Holland Model: Case CX210C Type: Crawler Excavator Manuals: Service Manual Publication Numbers: 47780398 (October 2014) and 47985408 (March 2016) Language: English Format: PDF Description Table of Content (Service Manual) Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Dozer Blade and Arm Platform, cab, bodywork and decals Special Tools Index Hydraulic Schematics Electrical Schematics Manual Extract: Hammer electric system – Dynamic description Crusher mode Purpose It is possible to set the maximum flow and the maximum pressure for each of the five crushers. Operation explanation 1. Each time the attachment select switch is pressed, it switches between Normal Mode → Breaker Mode → Crusher Mode → Normal Mode. The maximum flow for the switched mode is displayed on the monitor for 3 s. –  The crusher mode only has Crusher Mode 1 in the initial state, but a mode can be added on the flow setting screen. 2. Crusher can be used by selecting crusher mode. – Set the maximum flow and maximum pressure first on the flow setting screen. – If the set flow rate requires 2 pumps flow, 2 pumps flow is performed. 3. When the key is turned "OFF" once, then "ON" again, the attachment mode selected previously is retained.
