Case CX210D Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 3746 pages Specifications: • Brand: New Holland • Model: CX210D • Type: Excavator • Manuals: Service Manual • Publication Numbers: 47961273 (Jan 2016) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Platform, cab, bodywork and decals Special Tools Index Hydraulic Schematics Electrical Schematics Manual Extract: Exhaust gas temperature (EGT) sensor installation 1. Clean the old anti-seize lubricant on the sleeve nut, and apply new anti-seize lubricant to the threaded portion of the sleeve nut. 2. Apply anti-seize lubricant to the EGT sensor. NOTE: Apply High Temperature Stainless Never- Seez: 5-87411-039-0, manufactured by Bostik in the U.S., etc. to the threaded portion of the EGT sensor. 3. Temporarily tighten the EGT sensor to the oxidation catalyst assembly. NOTICE: Do not subject the tip of the exhaust gas temperature sensor to shock when installing. Replace the oxidation catalyst assembly if damage has been found in the sensor installation section of the oxidation catalyst assembly. NOTICE: To avoid damaging the sensor installation sections due to sensor incorrect assembly, tighten it by hand. 4. Final tighten the EGT sensor to the oxidation catalyst assembly. Tightening torque: 30 N·m (22.1 lb ft) 5. Connect the harness connector to the exhaust gas temperature sensor. NOTICE: Be careful not to twist the harness. 6. Start the engine after assembling each part, and check for gas leaks from each joint and for vibration.
