Case CX220C Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 1211 pages Specifications: • Brand: New Holland • Model: CX220C • Type: Excavator • Manuals: Service Manual • Publication Numbers: 71114551 (Mar 2015) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Platform, cab, bodywork and decals Special Tools Index Manual Extract: Exhaust muffler – Remove 1. Remove cover (1). 2. Remove 8 nuts (2) M8 and 2 U-bolts (3).: 13 mm 3. Remove 2 sems bolts (4) M10 X 35, 2 washers (5) and 2 nuts (6).: 17 mm 4. Separate clamp assembly (7) from muffler (8). 5. Remove muffler (8). Weight: 18 kg (40 lb)
