Case CX245D SR Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 4119 Pages & 3641 Pages Specifications: • Brand: New Holland • Model: CX245D SR • Type: Excavator • Manuals: Service Manual • Publication Numbers: 48149001 & 51429490 (Dec 2017) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Dozer blade and arm Platform, cab, bodywork and decals Special Tools Index Hydraulic Schematics Electrical Schematics Manual Extract: Camshaft installation 1. Align No.1 cylinder to the compression top dead center. I. Front cover marking II. 0° marking on the crankshaft damper 2. Apply the engine oil to the camshaft bearing. NOTE: Apply engine oil to the sliding surface of the bearing. NOTE: Apply engine oil after cleaning the bearing installation sections of the camshaft bearing and cylinder head. 3. Install the camshaft bearing to the cylinder head assembly. 4. Install the camshaft to the cylinder head assembly. NOTE: Mesh together the idle gear C and the camshaft gear so that the alignment mark on the camshaft gear matches the top surface of the cylinder head, and gently install the camshaft. 5. Check alignment mark of the camshaft gear. NOTE: Confirm that the alignment mark is not misaligned before installing the camshaft bearing cap. If the alignment mark is not at the correct position, reinstall the camshaft. 6. Apply the engine oil to the camshaft bearing. NOTE: Apply engine oil to the sliding surface of the bearing. NOTICE: Apply engine oil after cleaning the bearing installation sections of the camshaft bearing and camshaft bearing cap. 7. Install the camshaft bearing to the camshaft bearing cap. 8. Install the camshaft bearing cap to the cylinder head assembly. NOTE: Turn the camshaft bearing cap so that the arrow mark on the top surface faces the engine front side, and assemble in numerical order. Tightening torque: 28 N·m (21 lb ft) Engine oil application
