Case CX260C Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 2607 pages Specifications: • Brand: New Holland • Model: CX260C • Type: Excavator • Manuals: Service Manual • Publication Numbers: 47877014 (Jul 2015) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Dozer Blade and Arm Platform, cab, bodywork and decals Special Tools Index Hydraulic Schematics Electrical Schematics Manual Extract: Engine intake and exhaust system – Inspect Suction air system inspection – functions The suction air system consists of an air cleaner, suction air line, and turbocharger or the like. Suction air enters the engine through the air cleaner and intake manifold. Suction air system inspection Inspection performed when there is a possibility that there is an abnormality in the suction air system 1. Inspect the air cleaner. • There must be no excessive dirt or clogging. 2. If a problem is found, clean or replace. 3. Inspect the suction air line. • There must be no crushing, breakage, or air leaks. • There must be no inappropriate pipes or curves that would lead to increased suction air resistance. • There must be no lead valve breakage. 4. If a problem is found, perform repair or replacement. 5. Inspect the turbocharger. • There must be no abnormal rattling of the turbine shaft. • There must be no oil leakage. 6. If a problem is found, perform repair or replacement.
