Case CX290D Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 3950 pages Specifications: • Brand: New Holland • Model: CX290D • Type: Excavator • Manuals: Service Manual • Publication Numbers: 48155069 (Feb 2018) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Platform, cab, bodywork and decals Special Tools Index Hydraulic Schematics Electrical Schematics Manual Extract: Bucket Removal 1. Set the maximum operating radius posture and place the club bucket nail in an opened state on the ground. i Club bucket side pin ii. Arm side pin 2. Remove the pin (2) ring (1) by using a driver. Pull out the pins at the bucket side and the arm side. 3. Push out the pin (3) of club bucket side and pin (2) of arm side with a hammer (4) and striking rod (5) to remove the club bucket (1). • When pulling out the pin, be careful not to damage the attached O-ring and dust seal.
