Case CX31, CX36 Excavator Service Manual Workshop Guide

Manual Included: Service Manual: 630 pages Specifications: Brand: Case Model: Case CX31 and CX36 Type: Excavator Manuals: Service Manual Publication Numbers: S5W0002E Language: English Format: PDF Description Table of Contents Specification Maintenance System Disassembling Troubleshooting Engine Installation Procedures for Optional Attachments Manual Extract: CANOPY REMOVAL 1. Remove the floor mat (A12). 2. Removing the cover (7) Only when removing the handrail in Step (4) described below, unscrew one M8X20 SEMS bolt (6) and one M8X25 SEMS bolt (10) to remove the cover (7). 3. Removing canopy assembly Unscrew one M16X60 caps crew (7) and two M16X100 caps crews (10) to remove the support (24) and the canopy (1) in one piece. Canopy weight : 84 kg ( 185 lb.) 4. Removing handrail (12) Unscrew one M10X40 SEMS bolt (13) and two M10X25 SEMS bolts (15) to remove the handrail (12). 5. Install the canopy in reverse order of the removal.
