Case CX35B, CX39B Series 2 Mini Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 1159 pages Specifications: • Brand: New Holland • Model: CX35B, CX39B Mini • Type: Excavator Series 2 • Manuals: Service Manual • Publication Numbers: 47574272B (Mar 2014) • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulic System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical Systems Booms, dippers and buckets Dozer blade and arm Platform, Cab, bodywork and decals Manual Extract Inspection A floating bearing is adopted. Since the bearing moves with the turbine shaft as the oil films are formed both inside and outside the bearing, the bearing sliding speed is slower than the turbine shaft speed, resulting in higher dynamic stability. Compressor side sealing mechanism To prevent the intake air and oil form leaking, a seal ring and a seal plate are provided to form a double wall structure on the rear side of the compressor impeller. Exhaust valve When the blower side pressure (intake air pressure) exceeds the specified level, the exhaust gas at the turbine inlet is partially bypassed to the exhaust discharge side to control the turbine RPM so as to maintain the intake pressure at the specified level for improving the response to load variation in the low to medium speed range and to minimize black smoke generation. It consists of a control assembly separated from the turbocharger and a valve assembly installed in the turbine impeller chamber
