Case CX470B Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 1509 pages Specifications: • Brand: Case • Model: CX470B • Type: Excavator • Manuals: Service Manual • Publication Number: 48004716 (Mar 2016) • Language: English • Format: PDF Description Table of Contents General Information Engine Fuel System Frames and ballasting Electrical systems Undercarriage Drive Train Upper structure Hydraulics Upper structure Manual Extract: Minimum flow adjustment Loosen the hexagon nut (808) and tighten (or loosen) the hexagon socket head locking screw (953) to adjust the flow control characteristic. Similar to the maximum flow adjustment, this does not change other control characteristic. However, if the hexagon socket head locking screw is tightened too much, the required power may increase at the time of maximum discharge pressure (during relief), so adjust this carefully.
