Case CX490C Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 2835 Pages & 2859 Pages Specifications: • Brand: New Holland • Model: CX490C and CX 500C • Type: Excavator • Manuals: Service Manual • Publication Numbers: 48098399, 48044249 (Sep 2016), 4795146 (Feb 2016) and • Language: English • Format: PDF Description Table of Contents Content Introduction Engine Hydraulics System Frames and Ballasting Tracks and Track Suspension Cab Climate Control Electrical System Booms, dippers and buckets Platform, cab, bodywork and decals Special Tools Index Hydraulic Schematics Electrical Schematics Manual Extract: Fuel leak-off pipe installation 1. Temporarily tighten the fuel leak-off pipe to the common rail assembly. 2. Temporarily tighten the fuel leak-off pipe to the fuel supply pump. 3. Temporarily tighten the fuel leak-off pipe to the cylinder head and fuel filter bracket. 4. Temporarily tighten the fuel leak-off pipe to the pipe bracket. 5. Securely tighten the fuel leak-off pipe to the fuel supply pump. Tightening torque: 17 N·m (13 lb ft) 6. Securely tighten the fuel leak-off pipe to the common rail assembly. Tightening torque: 20 N·m (15 lb ft) 7. Completely tighten the fuel leak-off pipe to the cylinder head. Tightening torque: 41 N·m (30 lb ft) 8. Completely tighten the fuel leak-off pipe to the fuel filter bracket. Tightening torque: 41 N·m (30 lb ft) 9. Completely tighten the fuel leak-off pipe to the pipe bracket. Tightening torque: 41 N·m (30 lb ft)
