Case CX800B Crawler Excavator Service Manual Workshop Guide

Manual Included: • Service Manual: 2710 pages Specifications: • Brand: New Holland • Model: CX800B • Type: Excavator • Manuals: Service Manual • Publication Numbers: 48020292 (June 2016) • Language: English • Format: PDF Description Table of Contents Contents Introduction Engine Hydraulic systems Frames and ballasting Tracks and track suspension Cab climate control Electrical systems Booms, dippers and buckets Platform, cab, bodywork and decals Special Tool index Hydraulic Schematics Electrical Schematics Manual Extract:  Turbocharger exhaust pipe installation 1. Install the gasket to the turbocharger exhaust pipe (1). NOTICE: Make sure to install the gasket with its yellow marking surface installed to the turbocharger exhaust pipe (1) so that it can be seen. Do not deform the gasket when installing. Install a new gasket. Do not reuse the gasket. 2. Install the turbocharger exhaust pipe (1) to the turbocharger assembly (2). NOTE: Install the V-band (3) to the turbocharger exhaust pipe (1). NOTICE: Make sure there are no gasket fragments in the turbocharger exhaust pipe (1). Insert the turbocharger exhaust pipe (1) until it makes full contact. Tightening torque: 16 N·m (11.80 lb ft) PAWE1BSH005601 72 3. Install the turbocharger exhaust pipe (3) to the bracket. Tightening torque: 50 N·m (36.88 lb ft) 1. Exhaust pipe bracket 2. V-band
