CAT EC25N2, EC25EN2, EC25LN2 Forklift Lift Truck Service Manual

CAT EC25N2, EC25EN2, EC25LN2 Forklift Service Manual: 417 Pages Operation and Maintenance Manual: 189 Pages Controller Manual: 216 Pages Publication 99759-8N200 English Format: PDF Description Caterpillar CAT EC25N2, EC25EN2, EC25LN2 Lift Truck Manual Lift Truck Forklift Model : EC25N2, EC25EN2, EC25LN2 Publication 99759-8N200 English Format: PDF CAT EC25N2, EC25EN2, EC25LN2 Forklift Service Manual: 417 Pages Operation and Maintenance Manual: 189 Pages Controller Manual: 216 Pages Forklift Manual Table of Content: General Information Electrical System Power Train Motor Transfer and Differential Front Axle Rear Axle Brake System Steering System Hydraulic System Masts and Forks Service Data Options Discharge electric charges stored in the inverters by using the following procedure. (1) Turn OFF the key switch. (2) Disconnect the battery plug/connector. (3) Remove the rear cover. (4) Place a 150 Ω/25 W resistor between P and N terminals in the traction inverter to discharge electric charges stored in the inverter. (5) After touching the resistor to the P and N terminals for approx. five seconds, measure the voltage between the terminals with a multimeter and confirm a reading of 5V or less. (6) Perform the same procedure for the pump inverter in order to discharge electric charges from all inverters. Check whether the resistance between + and – of the battery plug/connector on the lift truck side is 1 kΩ or more when connecting the battery plug/connector for the first time after maintenance. Note: Discharge electric charges completely before measuring. Longer measurement time reduces resistance value.
