Challenger MT485E, MT495E Tractor Service Manual Workshop Guide

Challenger MT485E, MT495E Tractor Workshop Manual : 1376 Pages Technician Service Book MT400E (Schematics and Electronics) : 646 Pages Spicer Dana 740, 735 Axle Service Manual: 176 Pages & 176 Pages Description Challenger MT485E, MT495E Tractor Repair Workshop Manual Manual for: AGCO Challenger 1000 Series Tractor Format: PDF Book Number: ACT0026660 English Issued May 2016 Challenger MT485E, MT495E Tractor Workshop Manual : 1376 Pages Technician Service Book MT400E (Schematics and Electronics) : 646 Pages Spicer Dana 740, 735 Axle Service Manual: 176 Pages & 176 Pages Challenger MT400E Series Manual TABLE OF CONTENTS Introduction Separation of assemblies Engine Clutch Gearbox Rear Axle Power Take off Front Axle Hydraulics Electricity Electronics Operator Environment Accessories Services Tools Extract  Challenger Tractor Manual MT485E, MT495E 6.14.5.4 Disassembling and reassembling a lift ram General On tractors fitted with the increased capacity linkage on the GPA20 + rear axle, the lift rams and their stroke are different to those of tractors which are not fitted with this option. Procedure 1. Start the engine and lower the lower arms of the hitch as far as possible using the tractor electronic control. 2. Disconnect the supply hose from the union (1) and remove the ram (6). Disassembly Procedure 1. Remove the elbow or straight union (1) (depending on assembly) fitted with its "O" ring. 2. Pull the rod from the ram (5) until the snap ring (4) appears in port O of the union. 3. Insert a screwdriver in this port and offset the snap ring into the adjacent V-shaped groove of the rod while turning the rod at the same time. 4. Remove the rod and the snap ring (4). Drive out the wiper seal (2) and the seal (3) (systematically discard the three parts). Reassembly Procedure 1. Carefully clean all the parts except for the seals. Dry them using a jet of compressed air. Replace any components found to be scratched or damaged. In case of seizure or if there is significant scratching on the functional components, replace the ram. 2. Lubricate the assemblies with clean transmission oil. 3. Assemble the ram. Carry out steps see Reassembly step 4, page 6-265 to see Reassembly step 2, page 6-265 (see  chapter Preliminary steps, page 6-265 ) in reverse order, applying the following operations: • Always fit a new snap ring and new seals. • Use a suitable fixture to fit the parts home without damaging the seals. • Carefully refit the rod into the ram body. 4. If necessary, repeat the step see step 3, page 6-265 for the second ram. Final steps Procedure 1. Lubricate the upper and lower pins of the ram with AS767 graphite grease or equivalent and refit the ram. Reconnect the supply hose. 2. Start the engine Using the tractor's electronic linkage system (ELC), activate the lower arms of the hitch in turn, from the high position to the low position and vice versa. 3. Check that the hitch operates correctly and that there is no leakage of oil around the rim of the ram.
