Challenger MT555D, MT565D, MT575D, MT585D, MT595D Tractor Workshop Manual Workshop Guide

Challenger MT555D, MT565D, MT575D, MT585D, MT595D Tractor Workshop Manual Workshop Guide

Regular price $50.00 USD
Regular price Sale price $50.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Challenger MT555D, MT565D, MT575D, MT585D, MT595D Tractor Workshop Manual : 4226 Pages Technician Service Book MT500D (Schematics and Electronics) : 763 Pages Operators Manual MT555D, MT565D, MT575D, MT585D, MT595D: 338 Pages & 196 Pages Parts Catalog TechStar CVT and AutoPower VI: 594 Pages & 466 Pages Engine Manual AGCO SISU: 113 Pages Spicer Dana Axle 735, 740, 750, 755 Axle Service Manual: 176 Pages Description Challenger MT555D, MT565D, MT575D, MT585D, MT595D Tractor Repair Workshop Manual Manual for: AGCO Challenger Format: PDF April 2012 No. 4373224M2 MT500D AutoPower IV Series MT500D AutoPower VI Series MT500D TechStar CVT Series North America – English Challenger MT555D, MT565D, MT575D, MT585D, MT595D Tractor Workshop Manual : 4226 Pages Technician Service Book MT500D (Schematics and Electronics) : 763 Pages Operators Manual MT555D, MT565D, MT575D, MT585D, MT595D: 338 Pages & 196 Pages Parts Catalog TechStar CVT and AutoPower VI: 594 Pages & 466 Pages Engine Manual AGCO SISU: 113 Pages Spicer Dana Axle 735, 740, 750, 755 Axle Service Manual: 176 Pages Challenger MT500D Series Manual TABLE OF CONTENTS Introduction Separation of assemblies Engine Clutch Gearbox Rear Axle Power Take off Front Axle Hydraulics Electricity Electronics Operator Environment Accessories Services Tools MT555D, MT565D, MT575D, MT585D, MT595D Manual Extract- Disassembling a wheel brake cylinder 1. Remove the hand brake cables. 2. Remove the wheel brake cylinder (35), upper and lower sections. 3. Loosen the screws. 4. Mark the position of the hand brake control lever in relation to the shaft. 5. Remove all parts, and take off all seals. 6. Seals to be changed on the wheel brake cylinder: – U seals (A) – "O" rings (B) – Lip seals (C) – "O" ring (D) Reassembly 1. Grease and fit a new "O" ring (D) in the piston groove. 2. Fit the parts in the specified order fig. 18. 3. Grease and fit a new "O" ring (B) in the housing groove. 4. Grease and fit a new lip seal (C) in the housing groove.
