Cummins Series C Engine Workshop Service Manual Workshop Guide

Manual Included: Workshop Manual: 732 Pages Specifications: Brand: Cummins Model: EX255 -, EX285 ,- FH270, G170 -, G200 -, FG75A -, FG85A + FG105A, W170 -, W190 -, W230 Type: C Engine Manuals: Workshop Manual Publication Numbers: 604.13.128 (Jul 2002) Language: English Format: PDF Description TABLE OF CONTENT: Workshop manual Introduction Engine Identification Troubleshooting Symptoms Complete Engine – Cylinder & Rocker Levers am Followers/Tappets Fuel System Injectors and Fuel Lines Lubricating Oil System Cooling System Air Intake System Exhaust System Compressed Air System Electrical Equipment Engine Testing Mounting Adaptations Miscellaneous Service Literature Foreword This manual provides instructions for troubleshooting and repairing this engine in the chassis. Component and assembly rebuild procedures are provided in the engine shop manual. Refer to Section i – Introduction for instructions on how to use this manual. Read and follow all safety instructions. Refer to the WARNING in the General Safety Instructions in Section i – Introduction. The manual is organized to guide a service technician through the logical steps of identifying and correcting problems related to the engine. This manual does not cover vehicle or equipment problems. Consult the vehicle or equipment manufacturer for repair procedures. A series of specific service manuals (for example: Shop, Specifications, and Alternative Repair) are available and can be ordered at The Repair Manual. The repair procedures used in this manual are recommended by  :, Some service procedures require the use of special service tools. Use the correct tools as described. Cummins Engine Company, Inc. encourages the user of this manual to report errors, omissions, and recommendations for improvement. The specifications and rebuild information in this manual are based on the information in effect at the time of printing. The latest technology and the highest quality components are used to manufacture Cummins engines.
