Doosan DX180LC Excavator Service Manual Workshop Guide

Manual Included: Shop Manual: 778 Pages Specifications: Brand: Doosan Excavator Model: DX180LC Serial Number: 5001 and Up Type: Excavator Manuals: Shop Manual Publication Number: K1024431AE Language: English Format: PDF Description Table of Contents:- Safety Track Excavator Safety…………………………………………………………….. SP000014 Specifications Specification for DX180LC ………………………………………………………… SP001028 General Maintenance General Maintenance Procedures ……………………………………………… SP000016 Standard Torques …………………………………………………………………….. SP000813 Upper Structure Cabin ………………………………………………………………………………………. SP000943 Counterweight…………………………………………………………………………… SP000940 Fuel Tank………………………………………………………………………………… SP001031 Fuel Transfer Pump …………………………………………………………………. SP000021 Swing Bearing………………………………………………………………………….. SP000022 Swing Reduction Gear ……………………………………………………………… SP000915 Lower Structure and Chassis Track Assembly ……………………………………………………………………….. SP001032 Engine and Drive Train Drive Coupling (Main Pump) …………………………………………………….. SP001033 Hydraulics Hydraulic System Troubleshooting, Testing and Adjustment ……….. SP001034 Accumulator……………………………………………………………………………… SP000028 Center Joint (Swivel) ………………………………………………………………… SP000029 Cylinders………………………………………………………………………………….. SP000030 Swing Motor…………………………………………………………………………….. SP000194 Travel Motor…………………………………………………………………………….. SP001036 Main Pump………………………………………………………………………………. SP001030 Main Control Valve…………………………………………………………………… SP001029 PTO Server……………………………………………………………………………… SP000933 Remote Control Valve (Work Lever / Joystick) ………………………….. SP000069 Travel Control Valve (with Damper) ………………………………………….. SP000070 Solenoid Valve Assembly………………………………………………………….. SP000445 Breaker EPPR Valve (Opt)……………………………………………………….. SP000192 Hydraulic Schematic (DX180LC) ……………………………………………….. SP001037 Electrical System Electrical System ……………………………………………………………………… SP001038 Electrical Schematic (DX180LC)………………………………………………… SP000936 Attachments Boom and Arm ………………………………………………………………………… SP001039 Bucket……………………………………………………………………………………… SP000939 Doosan DX180LC Manual Instruction Extract: Add-on Main Relief Valve Operation 1. This relief valve is inserted between the neutral path "HP" and the tank path "LP". Oil is filled into the inner space (C) through the orifice of the main poppet . The sleeve (2) and main poppet (1) are securely seated by the areal difference between "A" and "B". 2. When the pressure in the neutral path "HP" reaches the preset pilot spring force, the pilot poppet (3) will be opened. Oil flows around the pilot poppet (3), through the drill hole (E) and circular gap (D), and is guided to the tank path "LP". 3. When the pilot poppet (3) is opened, the pressure in the inner space (C) is decreased to open the main poppet (1). Therefore, the oil in "HP" flows directly through path "LP". How to Use The Doosan DX180LC Excavator Guide Manual: This manual provides information for servicing the DX180LC Doosan Excavator. All service procedures are broken down into detailed steps, listed in their recommended sequence. The manual uses both photographs and drawings to help locate and itemize components. The table of Contents on the preceding pages is your best tool for finding the service procedure you need. Be certain to observe all Safety information included in these pages. A schematic of each of the major engine systems is provided at the beginning of the section of the manual devoted to troubleshooting and repairing that particular system. Basic safety precautions are list in the Safety section of the Doosan DX180LC Excavator Service Manual. Additional safety precautions are list in the Safety section of the owner/operation/maintenance publication. Specific safety warnings for all these publications are provided in the description of operations where hazards exist. WARNING labels have also been put on the product to provide instructions and to identify specific hazards.
