Doosan DX235LCR Excavator Service Manual Workshop Guide

Manual Included: Shop Manual: 784 Pages Specifications: Brand: Doosan Excavator Model: DX235LCR Serial Number: 5001 and Up Type: Excavator Manuals: Shop Manual Publication Number: 950106-00081E Language: English Format: PDF Description Table of Contents:- Safety Track Excavator Safety………………………………………………………………. SP002112 Specifications Specification for DX235LCR……………………………………………………….. SP002113 General Maintenance General Maintenance Procedures……………………………………………….. SP000016 Standard Torques……………………………………………………………………… SP000813 Upper Structure Cabin ………………………………………………………………………………………. SP001938 Counterweight…………………………………………………………………………… SP002114 Fuel Tank…………………………………………………………………………………. SP002115 Fuel Transfer Pump…………………………………………………………………… SP000021 Swing Bearing…………………………………………………………………………… SP000022 Lower Structure and Chassis Track Assembly ………………………………………………………………………… SP002116 Engine and Drive Train Drive Coupling (Main Pump)……………………………………………………….. SP002117 Hydraulics Hydraulic System Troubleshooting, Testing and Adjustment …………… SP002118 Accumulator……………………………………………………………………………… SP000028 Center Joint (Swivel)………………………………………………………………….. SP001620 Cylinders………………………………………………………………………………….. SP002119 Swing Device……………………………………………………………………………. SP002120 Travel Motor……………………………………………………………………………… SP001621 Main Pump and PTO …………………………………………………………………. SP000988 Gear Pump ………………………………………………………………………………. SP000931 Main Control Valve ……………………………………………………………………. SP001024 Remote Control Valve (Work Lever / Joystick) ………………………………. SP000069 Travel Control Valve (with Damper)……………………………………………… SP002130 Solenoid Valve Assembly …………………………………………………………… SP001944 Breaker EPPR Valve (Opt) …………………………………………………………. SP000192 Hydraulic Schematic (DX235LCR) ………………………………………………. SP002121 Electrical System Electrical System ………………………………………………………………………. SP002122 Electrical Schematic (DX235LCR)……………………………………………….. SP002123 Attachments Boom and Arm………………………………………………………………………….. SP002124 Bucket……………………………………………………………………………………… SP000939 Doosan DX235LCR Manual Instruction Extract: Arm Installation Procedure Reattach the base of the arm cylinder to the mounting point on top of the boom. Begin with the arm securely supported on blocking in front of the excavator. Pregrease the mounting pin for the rod end of the arm cylinder and push it through the ears on the end of the arm. Attach a sling around that mounting pin and lift the arm with an assist crane until it is in position for the boom-arm pin connection to be made. Relieve hydraulic pressure from all points of the system before any hydraulic lines are opened, then carefully assemble hydraulic connections to the arm cylinder. Remove the sling from around the rod end arm cylinder pin, withdraw the pin and lift the body of the arm cylinder to re-pin the mounting connection. Boom Installation Procedure Before reassembling the attachment, make sure to inspect all bushings and pivot points of each section. To avoid damaging the seats, bushings should never be hammered or chiseled out of their seats. Installation is otherwise a reversal of the removal procedures. START-UP PROCEDURES Once the boom has been serviced, it should be lubricated as outlined in the initial start-up procedures of the operation manual. Refer How to Use The Doosan DX235LCR Excavator Guide Manual: This manual provides information for servicing the DX235LCR Doosan Excavator. All service procedures are broken down into detailed steps, listed in their recommended sequence. The manual uses both photographs and drawings to help locate and itemize components. The table of Contents on the preceding pages is your best tool for finding the service procedure you need. Be certain to observe all Safety information included in these pages. A schematic of each of the major engine systems is provided at the beginning of the section of the manual devoted to troubleshooting and repairing that particular system. Basic safety precautions are list in the Safety section of the Doosan DX235LCR Excavator Service Manual. Additional safety precautions are list in the Safety section of the owner/operation/maintenance publication. Specific safety warnings for all these publications are provided in the description of operations where hazards exist. WARNING labels have also been put on the product to provide instructions and to identify specific hazards.
