Doosan DX235N Excavator Service Manual Workshop Guide

Manual Included: Shop Manual: 808 Pages Specifications: Brand: Doosan Excavator Model: DX225LC Serial Number: 5001 and Up Type: Excavator Manuals: Shop Manual Publication Number: 950106-00303 Language: English Format: PDF Description DOOSAN DX235N Instruction Table of Content: Safety Track Excavator Safety …………………………………………………………….. SP000014 Specifications Specification for DX235NLC ……………………………………………………… SP002177 General Maintenance General Maintenance Procedures ……………………………………………… SP000016 Standard Torques …………………………………………………………………….. SP000813 Upper Structure Cabin ………………………………………………………………………………………. SP000943 Counterweight…………………………………………………………………………… SP000940 Fuel Tank………………………………………………………………………………… SP001014 Fuel Transfer Pump …………………………………………………………………. SP000021 Swing Bearing………………………………………………………………………….. SP001109 Swing Reduction Gear ……………………………………………………………… SP000915 Lower Structure and Chassis Track Assembly ……………………………………………………………………….. SP000911 Engine and Drive Train Drive Coupling (Main Pump) …………………………………………………….. SP001069 Hydraulics Hydraulic System Troubleshooting, Testing and Adjustment ……….. SP002178 Accumulator……………………………………………………………………………… SP000028 Center Joint (Swivel) ………………………………………………………………… SP001620 Cylinders………………………………………………………………………………….. SP000030 Swing Motor …………………………………………………………………………….. SP001013 Travel Motor…………………………………………………………………………….. SP001621 Gear Pump………………………………………………………………………………. SP000931 Main Control Valve…………………………………………………………………… SP001024 Axial Piston Pump……………………………………………………………………. SP001008 PTO Server ……………………………………………………………………………… SP000933 Remote Control Valve (Work Lever / Joystick) ………………………….. SP001646 Travel Control Valve (with Damper) ………………………………………….. SP001647 Solenoid Valve Assembly………………………………………………………….. SP001622 Breaker EPPR Valve (Opt)……………………………………………………….. SP000192 Hydraulic Schematic (DX225NLC/DX235NLC)…………………………….. SP001057 Electrical System Electrica System………………………………………………………………………. SP002182 Electrical Schematic (DX180LC/DX225LC/DX225NLC/DX235NLC).. SP000936 Attachments Boom and Arm………………………………………………………………………… SP000937 Bucket……………………………………………………………………………………… SP000939 Doosan DX235N Manual Instruction Extract: Remote Control Valve Structure The remote control valve contains four push rods, spring holders, spools and return springs, which are in the valve casing. The valve works as a pressure reduction valve. The housing has six ports, which include input port P, tank port T, and four secondary pressure ports. The electric horn button is installed in the valve handle. Gear pump pressure is used for operating control spools. Function 1. Neutral Position When the lever is in neutral mode, the spool is pushed upward by return spring. The force of balancing spring, which determines the secondary discharge pressure, is not transmitted to the spool. The input port is closed and the pressure of the output port is the same as the pressure of the tank port T. 2. Control Switch Pressing of the push rod starts to press the balance spring, whose force is transferred to the spool to connect the P and T ports, transferring the pilot pressure. Output pressure acts on the bottom of the spool and press the spool upwards until it is balanced with the force of the balance spring. In short, the second pressure (output pressure) changes in proportion to the pressing force of the balance spring. How to Use The Doosan DX235N Excavator Guide Manual: This manual provides information for servicing the DX235N Doosan Excavator. All service procedures are broken down into detailed steps, listed in their recommended sequence. The manual uses both photographs and drawings to help locate and itemize components. The table of Contents on the preceding pages is your best tool for finding the service procedure you need. Be certain to observe all Safety information included in these pages. A schematic of each of the major engine systems is provided at the beginning of the section of the manual devoted to troubleshooting and repairing that particular system. Basic safety precautions are list in the Safety section of the Doosan DX235N Excavator Service Manual. Additional safety precautions are list in the Safety section of the owner/operation/maintenance publication. Specific safety warnings for all these publications are provided in the description of operations where hazards exist. WARNING labels have also been put on the product to provide instructions and to identify specific hazards.
