Doosan DX255 Excavator Service Manual Workshop Guide

Manual Included: Shop Manual: 826 Pages Specifications: Brand: Doosan Excavator Model: DX255 Serial Number: 5001 and Up Type: Excavator Manuals: Shop Manual Publication Number: K1016585E Language: English Format: PDF Description Table of Contents:- Safety Track Excavator Safety………………………………………………………………. SP000014 Specifications Specification for DX255LC………………………………………………………….. SP001009 General Maintenance General Maintenance Procedures……………………………………………….. SP000016 Standard Torques……………………………………………………………………… SP000813 Upper Structure Cabin ………………………………………………………………………………………. SP000943 Counterweight…………………………………………………………………………… SP000940 Fuel Tank…………………………………………………………………………………. SP001012 Fuel Transfer Pump…………………………………………………………………… SP000021 Swing Bearing…………………………………………………………………………… SP001068 Swing Reduction Gear……………………………………………………………….. SP001015 Lower Structure and Chassis Track Assembly ………………………………………………………………………… SP001016 Engine and Drive Train Drive Coupling (Main Pump)……………………………………………………….. SP001069 Hydraulics Hydraulic System Troubleshooting, Testing and Adjustment …………… SP001017 Accumulator……………………………………………………………………………… SP000028 Center Joint (Swivel)………………………………………………………………….. SP000029 Cylinders………………………………………………………………………………….. SP000030 Swing Motor……………………………………………………………………………… SP001020 Travel Motor……………………………………………………………………………… SP001021 Gear Pump ………………………………………………………………………………. SP000931 Main Control Valve ……………………………………………………………………. SP000034 Axial Piston Pump……………………………………………………………………… SP001022 PTO Server………………………………………………………………………………. SP000933 Remote Control Valve (Work Lever / Joystick) ………………………………. SP000069 Travel Control Valve (with Damper)……………………………………………… SP000070 Solenoid Valve Assembly …………………………………………………………… SP000445 Breaker EPPR Valve (Opt) …………………………………………………………. SP000192 Hydraulic Schematic (DX255LC)…………………………………………………. SP001023 Electrical System Electrical System………………………………………………………………………. SP001025 Electrical Schematic (DX180LC/DX225LC/225NLC/255LC) ……………. SP000936 Attachments Boom and Arm………………………………………………………………………….. SP001026 Bucket……………………………………………………………………………………… SP000939 Doosan DX255 Manual Instruction Extract: Periodic, regular checks of bearing displacement should be made at least twice a year. Use a dial indicator. Push the attachment against the ground to lift the excavator off the ground and take measurements at 4 points, 90 apart, around the circumference of the bearing. Record and keep all measurements. Play in the bearing should increase minimally from one inspection to the next. Eventually, however, as the bearing begins to approach the limit of its service life, clearance increases become much more pronounced and the actual measured play in the bearing could exceed twice the value that was measured when the machine was new. How to Use The Doosan DX255 Excavator Guide Manual: This manual provides information for servicing the DX255 Doosan Excavator. All service procedures are broken down into detailed steps, listed in their recommended sequence. The manual uses both photographs and drawings to help locate and itemize components. The table of Contents on the preceding pages is your best tool for finding the service procedure you need. Be certain to observe all Safety information included in these pages. A schematic of each of the major engine systems is provided at the beginning of the section of the manual devoted to troubleshooting and repairing that particular system. Basic safety precautions are list in the Safety section of the Doosan DX255 Excavator Service Manual. Additional safety precautions are list in the Safety section of the owner/operation/maintenance publication. Specific safety warnings for all these publications are provided in the description of operations where hazards exist. WARNING labels have also been put on the product to provide instructions and to identify specific hazards.
