Fiat 115-90, 130-90, 140-90, 160-90, 180-90 Tractor Service Manual Workshop Guide

Brand: Fiat Trattori Equipment Type: Tractor 115-90, 130-90, 140-90, 160-90, 180-90 Format: PDF Language of the Manual: English Publication: 06910088 Fiat Trattori tractor 115-90, 130-90, 140-90, 160-90, 180-90 Workshop Repair Manual: 348 Pages Description Fiat 115-90, 130-90, 140-90, 160-90, 180-90 Tractor Service Manual Brand: Fiat Trattori Equipment Type: Tractor 115-90, 130-90, 140-90, 160-90, 180-90 Format: PDF Language of the Manual: English Publication: 06910088 Fiat Trattori tractor 115-90, 130-90, 140-90, 160-90, 180-90 Workshop Service Manual: 348 Pages Table of Content of the 115-90, 130-90, 140-90, 160-90, 180-90 Tractors Manual: General Specificaion Engine Power Train Front Axle-Steering Front Wheel Drive Hydraulic Lift Unit Electrical System Service Tools The Fiat Service Manual provides you with all the technical specification and information needed for you to properly service the Fiat Tractor 115-90, 130-90, 140-90, 160-90, 180-90 . By using this repair service manual in addition to your operators manual supplied, you should be able to correctly service and maintain your tractor. The manual describes the procedures of removal, disassembly, reassembly, troubleshooting, maintenance that have been found to be the easiest and least time consuming way to fix any issues with your tractor. There may be several other ways of completing the same job, but it has been established that the described methods are the best. Any diversion to these procedures mentioned in this manual are your own decisions. Anyone who performs repair and maintenance operations without complying with the procedures provided herein shall be responsible for any subsequent damages. Manual is applicable to: FIAT Tractorri 115-90, 130-90, 140-90, 160-90, 180-90 Model Tractors The manual is divided into separately numbered sections. • Two-digit sections whose second digit is zero contain: – tractor specification (OD); – tractor sub-assembly specification and data (10-Engine; 20-Power Train; 30-Front Axle-Steering; 40-Front Wheel Drive; SO-Hydraulic Lift Unit; 60-Electrical System; 90-Service Tools). • Two-digit sections whose second digit is from one to nine deal with overhaul of the sub-assemblies whose data are listed in the sections described above. The first digit is the same as that of the corresponding data section (e.g. 20 – Power Train, is associated with 22 – Clutch; 23 – Transmission and Splitter; 24 – Creeper, Mechanical Reverser, etc .. .). • A contents list is provided to facilitate retrieval of desired information. • The print number of the manual and the date of issue is shown at the bottom of each page.
