Fiat 570, 570DT, 670, 670DT Tractor Service Manual Workshop Guide

Brand: Fiat Trattori Equipment Type: Tractor 570, 570DT, 670, 670DT Format: PDF Language of the Manual: English Publication: 06910055 Fiat Trattori tractor 570, 570DT, 670, 670DT Workshop Repair Manual: 54 Pages Description Fiat 570, 570DT, 670, 670DT Tractor Service Manual Brand: Fiat Trattori Equipment Type: Tractor 570, 570DT, 670, 670DT Format: PDF Language of the Manual: English Publication: 06910055 Fiat Trattori tractor 570, 570DT, 670, 670DT Workshop Service Manual: 54 Pages Table of Content of the 570, 570DT, 670, 670DT Tractors Manual: General Specificaion Engine Power Train Front Axle-Steering Front Wheel Drive Hydraulic Lift Unit Electrical System Service Tools The Fiat Service Manual provides you with all the technical specification and information needed for you to properly service the Fiat Tractor 570, 570DT, 670, 670DT. By using this repair service manual in addition to your operators manual supplied, you should be able to correctly service and maintain your tractor. Manual Extract: Bevel Drive and Differential Adjustment 1. Bevel pinion bearing adjustment and shim thick-ness determination using special purpose tools (fig. c and d). Place the bevel pinion bearing cones (7 and 9) and spacer (8) on tool (E) 293752. Tighten nut (M) fully. Measure the depth (H4) of the tool pin below the top face. Dismantle, lubricate bearings with engine oil and reassemble on the tool, interposing the bevel drive carrier (10) with attached bearing cups. Tighten nut (M) fully, simultaneously rotating the bevel drive case through 10 turns to settle the bearings. Manual is applicable to: FIAT Tractorri 570, 570DT, 670, 670DT Model Tractors
