Ford 1200, 1300, 1500, 1700, 1900 Tractors Service Manual Workshop Guide

Brand: Ford New Holland Equipment Type: Tractor 1200, 1300, 1500, 1700, 1900 Format: PDF Language of the Manual: English Publication: 40130040 & I&T Ford New Holland Tractor 1200, 1300, 1500, 1700, 1900 Service Manual: 1174 Pages Description Ford 1200, 1300, 1500, 1700, 1900 Tractors Service Manual Brand: Ford New Holland Equipment Type: Tractor 1200, 1300, 1500, 1700, 1900 Format: PDF Language of the Manual: English Publication: 40130040 & I&T Ford New Holland Tractor 1200, 1300, 1500, 1700, 1900 Service Manual: 1174 Pages Table of Content of the 1200, 1300, 1500, 1700, 1900 Tractor Manual: Part 1 – ENGINE Chapter 1 – ENGINE AND LUBRICATION SYSTEM . . . . . . . . . . . 1-79 Chapter 2 – COOLING SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81-106 Part 2 – FUEL SYSTEM Chapter 1 – DIESEL FUEL SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . 1-22 Part 3 – ELECTRICAL SYSTEM Chapter 1 – GLOW PLUGS . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 1-11 Chapter 2 – STARTER SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-17 Chapter 3 – HORN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-27 Chapter 4 – BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29-43 Chapter 5 – SAFETY START SWITCH . . . . . . . . . . . . . . . . . . . . . . . 45-53 Chapter 6 – STARTER MOTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55-76 Chapter 7 -ALTERNATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . 77-121 Chapter 8-WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123-124 Part 4-TRANSMISSION AND CLUTCH Chapter 1 – CLUTCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..1-11 Chapter 2 -TRANSMISSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-34 Part 5 – DIFFERENTIAL, REAR AXLE, AND RELATED PARTS Chapter 1 – DIFFERENTIAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-28 Chapter 2 – REAR AXLE AND BRAKES . . . . . . . . . . . . . . . . . . . . . . 29-44 Part 6 – HYDRAULICS Chapter 1 – HYDRAULIC SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . .. 1-37 Part 7 – STEERING AND FRONT AXLE Chapter 1 – STEERING AND LINK SYSTEM . . . . . . . . . . . . . . . . . .. 1-10 Chapter 2 – FRONT AXLE AND RELATED PARTS . . . . . . . . . . . . . 11-41 Part 8 – WHEELS AND TIRES Chapter 1 – ADJUSTMENT AND WEIGHTING PROCEDURES . . . 1-5 Each tractor is equipped with an in-line, four-cycle, liquid-cooled, overhead valve diesel engine. The Models 1300, 1500, and 1700 tractors have a two cylinder engine while the largest of the tractors the Model 1900 – has a three-cylinder engine. The rated horsepower of the engines increase as the tractor size increases; with the Model 1500 being the lowest and the 1900 being the highest. The engine which is being used in a particular tractor model can be identified by a code number cast into the side of the cylinder block. Engine Code Tractor Model Horse Power LEK 802D 1300 16 LET 852C 1500 20 LE 892 1700 25 LEM 853 1900 30 All Parts are subdivided into Chapters which convey information on general operating principles, detailed inspection and overhaul procedures and, where applicable, specifics on troubleshooting, special tools and specifications of the Ford 1200, 1300, 1500, 1700, 1900. Any reference in this manual to right, left, rear, front, top or bottom is as viewed from the operator's seat. The information contained herein was correct at the time of going to print All data in Ford Tractor 1200, 1300, 1500, 1700, 1900 manual is subject to production variations and the illustrations do not necessarily depict tractors to standard build specifications. Some of the information in this manual is reprinted from the previous Repair Manual as the service information contained herein is equally applicable. First check the appropriate section to see if the model has a specific chapter.
