Ford 1320, 1520, 1620, 1715, 1720 Tractor Service Manual Workshop Guide

Brand: Ford New Holland Equipment Type: Tractor 1320, 1520, 1620, 1715, 1720 Format: PDF Language of the Manual: English Publication: 40132030 Issued 5/95 Ford New Holland Tractor 1320, 1520, 1620, 1715, 1720 Technical Manual: 594 Pages Ford New Holland Tractor Supplement Service Repair Manual – 82 Pages Description Ford 1320, 1520, 1620, 1715, 1720 Tractor Service Manual Brand: Ford New Holland Equipment Type: Tractor 1320, 1520, 1620, 1715, 1720 Format: PDF Language of the Manual: English Publication: 40132030 Issued 5/95 Ford New Holland Tractor 1320, 1520, 1620, 1715, 1720 Service Manual: 594 Pages Ford New Holland Tractor Supplement Service Manual – 82 Pages Table of Content of the 1320, 1520, 1620, 1715, 1720 Tractor Manual: Engine Systems Fuel System Electrical System Clutches Transmission Systems Power Take-Off Systems Differentail, Rear Axle and Brakes Hydraulic System Steering System Front Axle and Related Parts Wheels and Tires Separating The Tractor Supplement to 1320, 1520, 1720 Service Manual FOREWORD This repair manual provides information for the proper servicing and overhaul of Ford 1320, 1520, 1620, 1715 and 1720 Tractor Models and is an essential publication for all service personnel carrying out repairs and maintenance procedures. The Manual is divided into twelve PARTS, each sub-divided into Chapters. Each Chapter contains information on general operating principles, detailed inspection and overhaul and, where applicable, trouble shooting, special tools and specifications. The material contained in this Manual was correct at the time of going to print, but Ford New Holland, Inc. policy is one of continuous improvement and the right to change prices, specifications, equipment or design at anytime without notice is reserved. All data in this Manual is subject to production variations, so overall dimensions and weights should be considered as approximate only and the illustrations do not necessarily depict the unit to standard build specification. A. DESCRIPTION AND OPERATION This chapter describes the engine overhaul and repair procedures of the Models 1320, 1520, 1620, 1715 and 1720 tractors. Repair procedures are essentially the same for all models except as noted in the repair procedures. The tractors are equipped with three-cylinder in-line engines. They are all four cycle, overhead valve, liquid cooled engines. The engines are identified by a code number cast into the side of the cylinder block.
