Ford 70, 75 Lawn Tractor Service Manual Workshop Guide

Brand: Ford Equipment Type: Lawn and Garden Tractor Equipment Model: 70, 75 Format: PDF Language of the Manual: English Publication: 40007020 Ford Lawn Tractors 70, 75 Technical Manual: 36 Pages Description Ford 70, 75 Lawn Tractor Service Manual Brand: Ford Equipment Type: Lawn and Garden Tractor Equipment Model: 70, 75 Format: PDF Language of the Manual: English Publication: 40007020 Ford Lawn Tractors 70, 75 Service Manual: 36 Pages Table of Content of the 70, 75 Tractors Manual: This Manual Contains a Brief Description of the Ford 70 and 75 Lawn Tractors, and the Service Procedures for the Engine, the Electrical System, and the Transaxle. Included Are Directions for Gaining Access to the Above Components. Listing of the Manual Contents is on the Inside Back Cover. A Flat Rate Labor Guide for Servicing the Ford 70 and 75 Lawn Tractor is Listed on Page 34 More Detailed General Description, Instructions for Set-up, Operation, Maintenance and Lubrication, Adjustments and Belt Replacement, and General Specifications Are Found in the Operator's Manual, Se 3203. The Ford 70 and 75 Lawn Tractors have single cylinder, four cycle, gasoline engines rated at 7.0 horsepower. The difference between the two tractors is primarily in the components used for starting the engine. The Ford 70 uses a manual, or pull-type, starting mechanism. The Ford 75 has an electric starter, and therefore has a battery and an alternator for charging the battery. The 70 and the 75 both use a magneto for the ignition system. The transmission and rear axle-are combined in an assembly called a transaxle. This mechanism provides for three forward, and one reverse, gear ratios. The clutch is the belt-idler type. The foot pedal serves for both clutch and brake action. Depressing the pedal
