Ford 900, 901, 1801, 2000, 4000 Tractor Service Manual Workshop Guide

Brand: Ford Equipment Type: Tractor Equipment Model: 900, 901, 1801, 2000, 4000 Year Applicable: 1954 – 1964 Format: PDF Language of the Manual: English Publication: 40060090 Ford 900, 901, 1801, 2000, 4000 Technical Manual: 504 Pages Description Ford 900, 901, 1801, 2000, 4000 Tractor Service Manual Brand: Ford Equipment Type: Tractor Equipment Model: 900, 901, 1801, 2000, 4000 Year Applicable: 1954 – 1964 Format: PDF Language of the Manual: English Publication: 40060090 Ford 900, 901, 1801, 2000, 4000 Service Manual: 504 Pages Table of Content of the 900, 901, 1801, 2000, 4000 Tractors Manual: Engine Electrical System Ignition System Fuel and Exhaust System (Gasoline & Diesel) Cooling System Clutch Transmission Rear Axle Power Take-off Power Steering Row Crop Tractors & Industrial Tractors Front Axle Brakes Wheels and Tires Hydraulic System Operating Principle Maintenance The Ford Service Manual provides you with all the technical specification and information needed for you to properly service the Ford Tractor 900, 901, 1801, 2000, 4000. By using this repair service manual in addition to your operators manual supplied, you should be able to correctly service and maintain your tractor. The manual describes the procedures of removal, disassembly, reassembly, troubleshooting, maintenance that have been found to be the easiest and least time consuming way to fix any issues with your tractor. There may be several other ways of completing the same job, but it has been established that the described methods are the best. Any diversion to these procedures mentioned in this manual are your own decisions. DESCRIPTION AND OPERATION – SELECT-O-SPEED TRANSMISSION The Select-0-Speed Transmission is available in three models. The basic transmission remains unchanged for all tractors, and the differences exist only in the following Power Take-Off options : – No P.T.O. – Single speed independent engine-driven P. T.0. – Two speed independent engine driven P.T.0., and proportional ground speed P. T. 0. The 900, 901, 1801, 2000, 4000 Ford Tractor transmission provides for ease of control and high efficiency in the utilization of engine power and engine fuel. It is a manually selected, hydraulically controlled system, which transmits power from the engine through four planetary gear sets, providing the ten forward speed ratios and two reverse speed ratios to the final drive of the tractor. Park and Neutral positions are also provided. The Ford Tractor 900, 901, 1801, 2000, 4000 include a brief description and the principles of operation of the major assemblies in the transmission are discussed in this section. All design and operational differences between the transmission models are fully explained
