Ford LGT14D, LGT16D Lawn Tractor Service Manual Workshop Guide

Brand: Ford New Holland Equipment Type: Lawn Tractor Equipment Model: LGT14D, LGT16D Format: PDF Language of the Manual: English Publication: 40001420 Ford New Holland Lawn Tractor LGT14D, LGT16D Technical Manual: 288 Pages Description Ford LGT14D, LGT16D Lawn Tractor Service Manual Brand: Ford New Holland Equipment Type: Lawn Tractor Equipment Model: LGT14D, LGT16D Format: PDF Language of the Manual: English Publication: 40001420 •Ford New Holland Lawn Tractor LGT14D, LGT16D Service Manual: 288 Pages Table of Content of the 3600, 3230, 3610, 3430, 3910, 3930 Lawn Tractor Manual: Engine Fuel System Electrical System Hydrostatic Drive System Transaxle and Brake Steering and Front Axle Implement Drive Hydraulic Lift Wheel and Tires Mowers (44 and 48 inch mower) FOREWORD This manual provides information for the proper servicing and overhaul of the Ford 14D HP and 16D HP diesel LGT tractor models and is an essential publication for all service personnel carrying out repairs and maintenance procedures. The Manual is divided into ten PARTS, each sub-divided into Chapters. Each Chapter of the LGT14D, LGT16D Lawn Tractor contains information on general operating principles, detailed inspection and overhaul and, where applicable, trouble shooting, special tools and specifications. The material contained in this Manual was correct at the time of going to print but Ford New Holland, Inc. policy is one of continuous improvement and the right to change prices, specifications, equipment or design at anytime without notice is reserved. All data in this Manual Lawn Tractor LGT14D, LGT16D is subject to production variations, so overall dimensions should be considered as approximate only and the illustrations do not necessarily depict the unit to standard build specification. Engine chapter This chapter describes the overhaul and repair of the Ford 14D and 16D .HP LGT diesel engine. The Ford 14DLGT and 16DLGT HP tractors, which are equipped with a 3-cylinder in-line, four cycle, liquid cooled, overhead valve engine. The 14DLGT and 16DLGT HP engines are identified by code number E643 ( LGT 14D) and E673 (LGT 16D). The code number is cast in-to the left side of the block and readily accessible for reference.
