Hino Truck 2014 COE HEV Service Manual Workshop Guide

Format: PDF Language: English Hino 2014 Conventional Truck Manual for 238, 258LP, 268, 338 Series – 1009 Pages Hino 2014 Conventional Owners Manual – 446 Pages Troubleshooting Hino 2014 Manual – 919 Pages Hino J08E-VB and J08E-VC Engine Manual – 339 Pages Description Hino Truck 2014 COE HEV Service Manual This is the Repair and Service Manual for Hino Truck 2014 COE HEV Applicable for HINO 155, 155h, 195, 195h series, Format: PDF Language: English Hino 2014 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 836 Pages Hino 2014 COE HEV Owners Manual – 324 Pages Troubleshooting Hino 2014 Manual – 945 Pages Hino J05E Engine Manual – 647 Pages This workshop manual has been prepared to provide information covering repairs on 155, 155h, 195, 195h Series Hino 2014 COE HEV trucks. To use Hino Year 2014 and Series 155, 155h, 195, 195h Conventional trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino 2014 COE HEV Truck Manual: General Introduction Engine Hybrid System Transmission Clutch Propeller Shaft Axle Differential Brake Steering Frame and Frame Accessory Cab Mounting and Cab Suspension Body Construction Suspension Body Inside Accessory Body Outside Accessory Air Bag and Seat Belt Heater and Air Conditioner Electrical Control System Hino Truck 2014 COE HEV Manual Instruction Extract: 13. MOUNTING THE SHIFT POSITION SENSOR PROTECTOR (HV ONLY) (1) The left filler tube bracket of the transmission case is multiplied by the fingernail of the protector, and the position is decided. (2) Mount the bolt, with the filler tube bracket fixed to the back side of the automatic transmission assembly. Tightening Torque: 18 Nm {184 kgfcm, 13 lbfft} (3) Mount the bolt (2 pcs.), with the filler tube bracket and the protector to the left of the transmission case. Tightening Torque: 18 Nm {184 kgfcm, 13 lbfft} 14. MOUNTING THE SHIFT POSITION SENSOR PROTECTOR (1) The left bracket of the transmission case is multiplied by the fingernail of the protector, and the position is decided. (2) Mount the bolt, with the bracket fixed to the back side of the automatic transmission assembly. Tightening Torque: 18 Nm {184 kgfcm, 13 lbfft} (3) Mount the bolt (2 pcs.), with the bracket and the protector on the left of the transmission case. Tightening Torque: 18 Nm {184 kgfcm, 13 lbfft}
