Hino Truck 2014 Conventional Service Manual Workshop Guide

Format: PDF Language: English Hino 2014 Conventional Truck Manual for 238, 258LP, 268, 338 Series – 1009 Pages Hino 2014 Conventional Owners Manual – 446 Pages Troubleshooting Hino 2014 Manual – 919 Pages Hino J08E-VB and J08E-VC Engine Manual – 339 Pages Description Hino Truck 2014 Conventional Service Manual This is the Repair and Service Manual for Hino Truck 2014 Applicable for 238, 258LP, 268, 338 Series – Format: PDF Language: English Hino 2014 Conventional Truck Manual for 238, 258LP, 268, 338 Series – 1009 Pages Hino 2014 Conventional Owners Manual – 446 Pages Troubleshooting Hino 2014 Manual – 919 Pages Hino J08E-VB and J08E-VC Engine Manual – 339 Pages This workshop manual has been prepared to provide information covering repairs on 238, 258LP, 268, 338 Series Hino 2014 Conventional trucks. To use Hino 2014 Conventional trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino 2014 Conventional Truck Manual: General Introduction Clutch Equipment Clutch Main Unit Clutch Control Transmission Equipment Transmission Main Unit Transfer Main Unit Automatic Transmission P.t.o. (Power Take-off) Transmission / Transfer Control Propeller Shaft Differential Equipment Differential Carrier Index: Chassis Group 1/4 Propeller Shaft Equipment Brake Equipment Service Brake Abs & Asr Es Start (Easy & Smooth Start) System Exhaust Brake Retarder Brake Parking Brake Steering Equipment Steering Unit Power Steering Axle Equipment Front Axle Rear Axle Wheel & Tire Suspension Equipment Suspension Chassis Equipment Chassis Frame Coupler (5th Wheel) Pintle Hook Hino Truck 2014 Conventional Manual Instruction Extract: TORQUE VALUES FOR FASTENERS 1. GENERAL INFORMATION (1) The torque values on page DF02-1112 are for fasteners that have a light application of oil on the threads. • If the fasteners are dry: Increase the torque values by 10%. • If the fasteners have a heavy application of oil on the threads: Decrease the torque values by 10%. (2) If you do not know the size of the fastener that is being installed, measure the fastener. Use the following procedure. 2. AMERICAN STANDARD FASTENERS . a. Measure the diameter of the threads in inches, dimension X. b. Count the amount of threads in 1-inch. Example • American Standard size fastener is 0.50-13. • 0.50 is the diameter of the fastener in inches or dimension X. • 13 is the amount of threads in 1-inch. 3. METRIC FASTENERS . a. Measure the diameter of the threads in millimeters (mm), dimension X. b. Measure the distance of 10 threads, point to point in millimeters (mm), dimension Y. Make a note of dimension Y. c. Divide dimension Y by 10. The result will be the distance between two threads or pitch. Example • Metric size fastener is M8 x 1.25. M8 is the diameter of the fastener in millimeters (mm) or dimension X. • 1.25 is the distance between two threads or pitch. (1) Compare the size of fastener measured in 1. (2) above to the list of fasteners on page DF02-1112 to find the correct torque value.
