Hino Truck 2015 COE HEV Service Manual Workshop Guide

Format: PDF Language: English Hino 2015 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 842 Pages Hino 2015 COE HEV Owners Manual – 338 Pages Troubleshooting Hino 2015 Manual – 860 Pages Hino J05E Engine Manual – 647 Pages Description Hino Truck 2015 COE HEV Service Manual This is the Repair and Service Manual for Hino Truck 2015 COE HEV Applicable for HINO 155, 155h, 195, 195h series, Format: PDF Language: English Hino 2015 COE HEV Truck Manual for 155, 155h, 195, 195h Series – 842 Pages Hino 2015 COE HEV Owners Manual – 338 Pages Troubleshooting Hino 2015 Manual – 860 Pages Hino J05E Engine Manual – 647 Pages This workshop manual has been prepared to provide information covering repairs on 155, 155h, 195, 195h Series Hino 2015 COE HEV trucks. To use Hino Year 2015 and Series 155, 155h, 195, 195h Conventional trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino 2015 COE HEV Truck Manual: General Introduction Engine Hybrid System Transmission Clutch Propeller Shaft Axle Differential Brake Steering Frame and Frame Accessory Cab Mounting and Cab Suspension Body Construction Suspension Body Inside Accessory Body Outside Accessory Air Bag and Seat Belt Heater and Air Conditioner Electrical Control System Hino Truck 2015 COE HEV Manual Instruction Extract: INSTALLING THE DISC BRAKE 1. INSTALLING THE BLEEDER PLUG CAP 2. TEMPORARILY TIGHTENING THE BLEEDER PLUG 3. INSTALLING THE PISTON SEAL (1) Apply lithium soap base glycol grease to the entire circumference of the new piston seal and install it to the groove of the brake caliper. 4. INSTALLING THE PISTON (1) Apply lithium soap base glycol grease to the new disc caliper boots (2 pcs.). (2) Install the cylinder boots to the groove of the piston. ! CAUTION Install the cylinder boots securely to the groove of the piston. (3) Apply lithium soap base glycol grease thinly to the piston circumference and install it to the disc caliper. ! CAUTION Do not forcefully push the piston in. 5. INSTALLING THE DISC CALIPER BOOT (1) Install the disc caliper boots (2 pcs.) to the disc caliper. ! CAUTION Install the cylinder boot securely to the groove of the disc caliper.
