Hino Truck 2015 Conventional Service Manual Workshop Guide

Format: PDF Language: English Hino 2015 Conventional Truck Manual for 238, 258LP, 268, 338 Series – 1006 Pages Hino 2015 Conventional Owners Manual – 466 Pages Troubleshooting Hino 2015 Manual – 612 Pages Hino J08E-VB and J08E-VC Engine Manual – 344 Pages Description Hino Truck 2015 Conventional Service Manual This is the Repair and Service Manual for Hino Truck 2015 Applicable for 238, 258LP, 268, 338 Series Format: PDF Language: English Hino 2015 Conventional Truck Manual for 238, 258LP, 268, 338 Series – 1006 Pages Hino 2015 Conventional Owners Manual – 466 Pages Troubleshooting Hino 2015 Manual – 612 Pages Hino J08E-VB and J08E-VC Engine Manual – 344 Pages This workshop manual has been prepared to provide information covering repairs on 238, 258LP, 268, 338 Series Hino 2015 Conventional trucks. To use Hino 2015 Conventional trucks for years, smoothly, safely, and economically without trouble, it is important to perform inspections. Maintenance required to be performed is the responsibility of the owner. Some recommended repairs of your truck are mentioned. When making any repair of your truck, be careful not to be injured through improper procedures. As for maintenance items, refer to the Owners and Drivers Manual. All information and specifications in this manual are based upon the latest product information available at the time of printing. Table of Content For Hino 2015 Conventional Truck Manual: General Introduction Clutch Equipment Clutch Main Unit Clutch Control Transmission Equipment Transmission Main Unit Transfer Main Unit Automatic Transmission P.t.o. (Power Take-off) Transmission / Transfer Control Propeller Shaft Differential Equipment Differential Carrier Index: Chassis Group 1/4 Propeller Shaft Equipment Brake Equipment Service Brake Abs & Asr Es Start (Easy & Smooth Start) System Exhaust Brake Retarder Brake Parking Brake Steering Equipment Steering Unit Power Steering Axle Equipment Front Axle Rear Axle Wheel & Tire Suspension Equipment Suspension Chassis Equipment Chassis Frame Coupler (5th Wheel) Pintle Hook Cab Equipment Cab Electrical Equipment Electric Wire Hybrid System Hino Truck 2015 Conventional Manual Instruction Extract: 4. ADJUST THE RELEASE BEARING POSITION (1) Set 0.75″ (19 mm) dimension: With pedal down, turn adjusting ring to obtain approximately 0.75″ (19 mm). Turning the adjusting ring clockwise moves the release bearing toward the transmission. Turning the adjusting ring counterclockwise moves the release bearing toward the engine. (2) Check release travel dimensions with release yoke rotated toward release bearing, eliminating excess play in system. Having set this, depress pedal down fully releasing clutch and check release travel to settings shown. NOTICE It may be necessary to reduce the 0.75″ (19 mm) settings to be able to achieve 0.500″-0.562″ (13-14 mm) travel on some models of transmissions. 5. ADJUST THE FREE TRAVEL (1) Remove the return spring. (2) Loosen the lock nut and turn the push rod counterclockwise until the release bearing contacts the release lever plate or release lever. (3) Turn the push rod clockwise about 3 1/3 turns. Standard: Clearance between release bearing and release yoke: 3.18 mm {0.125 in.} (4) Tighten the lock nut.
